Descripción
[vc_row el_id="informacion"][vc_column][ultimate_heading margin_design_tab_text=""]The Transducer Simulator 4 is a fully functional simulator for replicating a wide range of load cell scenarios. An all-in-one carrying case provides the portability and convenience required by field technicians.[/ultimate_heading][vc_tta_accordion active_section="1" collapsible_all="true"][vc_tta_section title="Transducer Simulator 4 Specifications" tab_id="1534538444606-3d1090d2-ff0a"][vc_row_inner][vc_column_inner width="1/3"][vc_column_text]Range:
Choose any fixed setting ± 0.25 mV or 0.50 mV through a 10-turn wire-wound potentiometer with locking clutch, fixed and variable
Maximum Voltage:
15 V
Linearity:
Less than ± 0.02% full scale[/vc_column_text][/vc_column_inner][vc_column_inner width="1/3"][vc_column_text]Temperature Coefficient:
Absolute 5 ppm/°C; Tracking less than 0.5 ppm/°C
Load Factors:
Simulates 1, 2, 3, 4 or 8 350-ohm load cells or 2, 4, 6, 8 or 16 700-ohm load cells
Offset:
+0.25mV/V for use with digitally calibrated meters requiring positive dead load for calibration[/vc_column_text][/vc_column_inner][vc_column_inner width="1/3"][vc_column_text]Connectors:
Six-way binding posts, suitable for loose wires or banana jacks
Warranty:
One-year limited warranty[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_tta_section][/vc_tta_accordion][/vc_column][/vc_row][vc_row el_id="recursos"][vc_column][vc_empty_space height="20px"][ultimate_heading main_heading="Recursos / Descargas"][/ultimate_heading][vc_tta_accordion active_section="1" collapsible_all="true"][vc_tta_section title="Specifications Page" tab_id="1521654929872-40541558-89ff"][vc_column_text]
| TITLE | VIEW | ACTION |
|---|---|---|
| Transducer Simulator 4 |
[/vc_column_text][/vc_tta_section][vc_tta_section title="Manuales" tab_id="1521655180754-e9ee7f8d-3f84"][vc_column_text]
| TITLE | VERSION | REVISION | VIEW | |
|---|---|---|---|---|
| Transducer Simulator 4 Operating Instructions | -- | B | View |
[/vc_column_text][/vc_tta_section][/vc_tta_accordion][/vc_column][/vc_row][vc_row el_id="partes"][vc_column][vc_empty_space height="20px"][ultimate_heading main_heading="PARTES"][/ultimate_heading][vc_accordion][vc_accordion_tab title=""][vc_column_text]
| PART # | PRODUCT DESCRIPTION | LIST PRICE | CART |
|---|---|---|---|
| 22513 | Simulator,Scale-Pro 4 Transducer 0-3mV/V W/Vernier Control From -.50mV/V To +3.5mV/V Simulates 1,2,3,4 or 8 Load Cells NEMA 4X |
|
[/vc_column_text][/vc_accordion_tab][/vc_accordion][/vc_column][/vc_row][vc_row el_id="opciones"][vc_column][vc_empty_space height="20px"][ultimate_heading main_heading="OPCIONES"][/ultimate_heading][vc_accordion][vc_accordion_tab title=""][vc_column_text]
| PART # | PRODUCT DESCRIPTION | LIST PRICE | CART |
|---|---|---|---|
| 21116 | Cable,Interface Simulator I 3 |
|
[/vc_column_text][/vc_accordion_tab][/vc_accordion][/vc_column][/vc_row][vc_row el_id="repuestos"][vc_column][vc_empty_space height="20px"][ultimate_heading main_heading="PIEZAS DE REPUESTOS"][/ultimate_heading][vc_accordion][vc_accordion_tab title=""][vc_column_text]Las piezas de repuesto solo se pueden comprar a través de distribuidores capacitados y autorizados.
Para localizar un distribuidor en su área, llámenos al 997-59665 o complete una solicitud en línea.[/vc_column_text][/vc_accordion_tab][/vc_accordion][/vc_column][/vc_row]
