SURVIVOR® PL Rail Scale

  • 85 to 170 ton gross capacity
  • 85 ton sectional capacity
  • 12 ft 6 in, 15 ft, 18 ft, 25 ft module sizes available
  • 7 ft 8 in platform width
  • 18.5 in low profile design
  • Bolted checkered steel top plate
  • Designed for 115 lb and 132 lb rail
  • Longitudinal and lateral checking assemblies with top access
  • 100K CSP1-100K load cells
  • Lightning and surge suppression kit
  • Rail clips for deck
  • Anti-creep angles
  • Low-profile, above-grade installation
  • Load cells accessible from sides of scale
  • Copper transient bypass cables
  • In-bridge conduit runs
  • NTEP Certified, CC#02-087
  • Accuracy is 0.1% in accordance with NIST, AAR and AREMA requirements *Accuracy is based on rail cars uncoupled at both ends

Descripción

SURVIVOR railroad track scales incorporate Rice Lake's best-in-class weighbridge design to create a rugged, accurate, heavy-duty weighing system. Used in static weighing operations, the SURVIVOR PL Modular Type railroad track scale excels in high-accuracy, Legal for Trade weighing and meets AREMA and Cooper E-80 design specifications.

The SURVIVOR PL is a low-profile, pitless, modular railroad track scale. This heavy-duty workhorse is manufactured with more steel content than competitive models to provide decades of accurate rail car weighing. Both full-draft and two-draft weighing is available.

Due to the variety of configurations, please consult the factory to discuss application requirements and for complete specifications and price quotations.
