Descripción
The diamond treadplate and rigid structural-steel channel frame provide durability for weighing sheep, goats, cattle, hogs, horses and more. The SLV animal livestock scale can be customized for retrofit or unique applications.
RoughDeck SLV Dimensions
| Dimensions | |||||
| 3 ft x 8 ft | |||||
| A | 99.12 in | I | 2.625 in | ||
| B | 45.56 in | J | 3.375 in | ||
| C | 7.88 in | K | 29.25 in | ||
| D | 36.95 in | L | 36 in | ||
| E | 65.45 in | M | 32.75 in | ||
| F | 74.00 in | N | 3.50 in | ||
| G | 95.00 in | O | 77.58 in | ||
| H | 90.75 in | ||||
| 4 ft x 8 ft | |||||
| A | 99.12 in | I | 2.625 in | ||
| B | 45.56 in | J | 3.375 in | ||
| C | 7.88 in | K | 41.250 in | ||
| D | 36.95 in | L | 48 in | ||
| E | 65.45 in | M | 44.75 in | ||
| F | 74.00 in | N | 3.50 in | ||
| G | 95.00 in | O | 77.58 in | ||
| H | 90.75 in | ||||
JB8SP TuffSeal Signal Trim Junction Box Specifications
Cable Fittings:
(9) 3/8 in NPT 0.157 in-0.314 in
(2) 1/2 in NPT 0.272 in-0.472 in
(1) PreVent™ breather unit
(9) 3/8 in NPT 0.157 in-0.314 in
(2) 1/2 in NPT 0.272 in-0.472 in
(1) PreVent™ breather unit
Enclosure:
Molded FRP (NEMA Type 4X) enclosure with overlapping solid cover, stainless steel screws
Connectors:
Pluggable screw type, 12-28 AWG
Pluggable screw type, 12-28 AWG
Trimming:
Individual cell trim, range
Potentiometers:
100,000 ohm, 25 turn cermet
Circuit Board:
5.7 in x 7.2 in with conformal coating
5.7 in x 7.2 in with conformal coating
Warranty:
One-year warranty
