Descripción

Install loop detector systems from Rice Lake below ground at the entry or exit of your truck scale to easily detect vehicle movement. Loop detectors easily install beneath asphalt, concrete or blacktop.

EMX Lite Preformed Loops Specifications

Vehicle Loop Detector Power:
The detector is available in the following voltages: 12 VAC/DC, 24VAC, 24VDC, 110 VAC, 220 VAC. Maximum current draw 100mA

Low Power:
Detector is available with maximum current draw of 60mA

Temperature:
-40 to 180°F

Enclosure:
Extruded anodized aluminum,
(H x W x D) 3.25 x 2.56 x 3.65in (83 x 40 x 90mm)
Output Relays:
5A/125 VAC standard version, 1A/125 VAC low current version

Connector:
86CP11 compatible with 11-Pin Octal DIN-rail mountable socket or wire harness

EMX Lite Preformed loops Operating Temperature:
-60 to 260ºF

Overall Diameter of Loop Wire:
0.26in
Loop Dimensions:
4 x 6ft thru 4 x 12ft standard, custom sizes available

Lead-in-Wire:
50ft long, twisted wire in PVC jacket

Loop Wire Approvals:
UL subject 13, Type PLTC 300V, 90C passes IEEE-328,210,000, BTU Flame Test
Pennsylvania, Bureau of Deep Mine Safety, Approval P-MWMS-1-85
