Descripción
Output Current Span:
4 to 20 mA; 0 to 20 mA
Input for 16 mA Span:
3 mV to 62 mV
Zero Adjust:
12 mA
Amplifier:
Cell sensitivity (10 volts excitation):
0.3 mV/V to 6.2 mV/V
Output:
Current: 0 to 20 mA
Bridge Excitation Supply:
Adjustment range: 5 to 15 Volts
Power Requirements:
Input Voltage: 10 to 36 Volts DC
Input current with 150 mA B+ load: 0.17 A at 36 V to 0.7 A at 10 V
Input current with one 350 Ω bridge: 0.1 A at 36 V to 0.35 A at 10 V
Operating Temperature Range:
-13°F to 131°F (-25°C to 55°C)
Packaging:
Epoxy potted plastic enclosure with exposed screw terminal connections
Weight:
2 lb (0.9 kg)
Warranty:
One-year limited warranty
